Morbidelli M600/800F

Overview

The Morbidelli M600/800F is a modular CNC machining centre purpose-built for simultaneous routing and drilling operations in industrial woodworking production. As a mid-to-large format machining solution, it delivers dual-spindle capability—combining a high-speed routing unit up to 24,000 rpm with independent vertical and horizontal drilling spindles—enabling complex multi-operation workflows on single workpiece setups without intermediate repositioning. The machine's technical architecture centres on flexible working envelope options (ranging from 3650×1600 mm to 6170×2120 mm) with vectorial XY axis speeds of 127 m/min, supported by independent tool changers holding up to 54 tools. The drilling unit can deploy up to 38 vertical spindles and 12 horizontal spindles simultaneously at 8,000 rpm, with integrated blade capacity to 160 mm diameter (0-90° rotation), enabling complex hole patterns and pocket drilling in single passes. The M600 variant provides 250 mm Z-axis clearance while the M800 extends to 350 mm, accommodating thicker stock and deeper cavity operations. Power routing reaches 17 kW (23 hp maximum), supporting both high-speed finishing and aggressive material removal in hardwoods and engineered panels. This machine class serves industrial woodworking operations processing panel-based materials at production volumes exceeding 100+ parts monthly, particularly those requiring integrated routing contours with precision multi-spindle drilling patterns. Typical users operate 10-50 person facilities managing furniture component production, cabinetry manufacturing, or architectural millwork where labour cost per unit justifies equipment investment. The M600/800F targets workshops handling solid wood panels, MDF, plywood, and composite boards up to full sheet dimensions, where single-machine workflow consolidation (routing + drilling + blade operations) reduces material handling complexity and tool changeover downtime.

Applications

furniture panel processing

Medium workshop

Furniture makers processing table tops, wardrobe carcasses, and desk panels use the modular working envelope (available up to 6170×2120 mm) to machine large single pieces or nest 4–6 smaller components per cycle. The dual Z-clearance options (250 mm M600 / 350 mm M800) enable processing of 40–60 mm thick solid wood and edge-banding operations, while simultaneous drilling and routing handle joinery (dowel holes, pocket holes) and edge profiling in one setup. Output: 80–150 finished panels daily with minimal secondary hand assembly.

cabinet component production

Industrial

Manufacturers producing cabinet sides, shelving, and face frames leverage the M600/800F's 38 vertical spindles for drilling aligned shelf-pin holes, hinge cup pockets, and cable management apertures across multiple workpieces in single cycles. The integrated 17 kW routing unit simultaneously profiles front edges and decorative grooves on MDF or veneer-faced panels, while the 127 m/min XY speed maintains sub-15 minute cycle times for 1200×600 mm cabinet blanks. Typical production: 150–400 cabinet components per shift with <2% rework due to CNC repeatability.

custom architectural millwork

Medium workshop

Architectural woodshops producing bespoke doors, mouldings, and custom cabinetry exploit the 54-tool changer and horizontal spindle capability (up to 12 units) to machine complex edge details, integrated hardware mounting, and relief carving on single runs. The independent routing and drilling units eliminate tool-change delays when alternating between profile routing, precision drilling for hardware installation, and shallow carving—critical for one-off or small-batch custom work where setup flexibility outweighs pure throughput.

industrial batch production

Industrial

High-volume producers of standardized components (drawer fronts, partition panels, structural blanks) maximize the M600/800F's vectorial speed (127 m/min XY) and 350 mm Z clearance (M800) to achieve consistent 8–12 minute cycle times on nested sheet layouts, yielding 400–600 finished blanks per 8-hour shift. The independent spindle architecture handles concurrent routing of edge banding and drilling of assembly holes without workflow interruption, reducing per-unit labour cost below hand-operated alternatives.

Specifications

Working Areas

X-Y Axes Dimensions3650x1600 | 3650x1840 | 3650x2120 | 4970x1600 | 4970x1840 | 4970x2120 | 6170x1600 | 6170x1840 | 6170x2120 mm

Axes

Vectorial Speed X-Y Axes127 m/min

Z Axis Speed30 m/min

Z Axis Panel Passage (M600)250 mm

Z Axis Panel Passage (M800)350 mm

Routing Unit

Motor Power (max.)17 (23) kW (hp)

Rotation Speed (max.)24000 rpm

Tool Changers
