Nova SI X

Overview

The Nova SI X is a precision sliding table saw engineered for high-volume cross-cutting and angled operations in professional solid wood processing environments. Built on SCM's proven platform, it combines a powered and programmed sawblade movement system with ±46° double-tilt capability, enabling both standard perpendicular cuts and complex angled work in a single setup without manual blade repositioning. The machine's technical foundation centers on a 400mm maximum blade diameter with variable projection depths (136mm, 97mm, or 60mm from table), paired with a 1270mm rip capacity and sliding table strokes up to 3800mm for full-width squaring operations. Motor options range from 7–8 kW at either 50 or 60 Hz, delivering consistent performance across global voltage standards while maintaining the cutting power required for dense hardwoods and engineered panels. The programmed blade control system eliminates manual adjustment downtime, critical for production environments where consistency across hundreds of pieces daily is non-negotiable. The Nova SI X serves medium to industrial woodworking shops focused on component manufacturing—cabinet parts, door frames, stair treads, and architectural millwork where edge quality and dimensional repeatability directly impact final assembly. Its dual-tilt architecture and powered indexing make it particularly suited to operations requiring compound angles or multiple cut sequences on the same stock, reducing material waste and re-handling. The combination of 1270mm width capacity and extended squaring stroke (up to 3800mm) positions it for both narrow component work and full-width panel processing, accommodating production schedules with mixed part geometry.

Applications

cabinet making

Medium workshop

Cabinet makers use the Nova SI X to cross-cut component blanks (stiles, rails, panels) to exact length with the 3800mm squaring stroke and rip fence, processing 50–200 parts daily. The ±46° tilt enables frame joints and angled door details without secondary equipment, while the 1270mm capacity handles standard cabinet widths in a single pass, reducing material scrap and handling time.

solid wood panel processing

Industrial

High-volume panel processors use the Nova SI X to break down wide glued-up blanks and engineered panel stock into components with straight or angled edges. The 1270mm rip capacity and variable blade projection (60–136mm) allow fine control over cutting depth for veneered panels, while the programmed indexing system achieves dimensional consistency across production runs of 1000+ pieces per shift.

architectural millwork

Industrial

Custom millwork shops leverage the programmed blade positioning and compound-tilt system to produce frames, casings, and trim with angled or chamfered edges at production scale. The powered sawblade movement ensures repeatable angle cuts across batches of 500+ linear feet of material, critical for architectural specifications where tolerance stack-up across site assembly is eliminated.

staircase component production

Medium workshop

Stair manufacturers exploit the ±46° tilting capacity to cut angled treads, stringers, and riser blanks that require precise bevel geometry. The 1270mm cutting width accommodates full-width tread blanks, while the extended squaring stroke (2250–3800mm) processes long stringer pieces in a single operation, reducing joint lines and improving visual continuity.

Specifications

Routing Unit

Max. saw blade diameter with scoring blade (option) mounted400 mm

Maximum saw blade projection from table136 | 97 | 60 mm

Working Areas

Cutting width on rip fence (Rip capacity)1270 mm

Max. squaring stroke of sliding table saw2250 | 3800 mm

Motor

Three-phase motor starting from7 | 8 kW

Three-phase motor frequency50 | 60 Hz
