Class S 630 - Class S 520

The Class S 630 and Class S 520 are precision thicknessing planers engineered for consistent stock removal and dimensional accuracy across solid wood processing workflows. Both models feature a 7 kW (9.5 HP) main motor and deliver up to 8 mm maximum stock removal per pass, making them suitable for intermediate to finish planing operations on hardwoods and softwoods alike.

These machines differentiate themselves through adjustable feed speed control (4–20 m/min) that enables operators to optimize surface finish quality versus production throughput based on wood species and grain direction. The Class S 630 accommodates workpieces up to 630 mm wide across a 640×1000 mm work table, while the Class S 520 processes stock up to 520 mm wide on a 530×900 mm table. Both accept planing heights from 3.5 to 300 mm, providing flexibility for processing everything from thin veneered panels to solid dimensioned blanks.

The Class S series targets small to medium woodworking facilities and custom millwork shops requiring reliable thicknessing performance without the footprint or investment of larger industrial planers. The sturdy construction and practical control layout support both semi-skilled operators and experienced craftspeople, making these machines suited to job-shop environments where material diversity and batch flexibility matter as much as consistent dimensional output.

Compared to entry-level portable planers, the Class S models deliver superior table stability, wider processing capacity, and feed speed control that reduces tearout on difficult grain. Versus industrial 4-square systems, they occupy less floor space and require lower capital investment while maintaining respectable throughput for shops processing 500–2000 board-feet monthly.
